Using Authorized IP Managers
Overview
Overview
Authorized IP Manager Features
Feature Default Menu CLI Web
Listing (Showing) Authorized
Managers
n/a page 14-5 page 14-6 page 14-8
Configuring Authorized IP
Managers
None page 14-5 page 14-6 page 14-8
Building IP Masks n/a page 14-10 page 14-10 page 14-10
Operating and Troubleshooting
Notes
n/a page 14-13 page 14-13 page 14-13
The Authorized IP Managers feature uses IP addresses and masks to deter-
mine which stations (PCs or workstations) can access the switch through the
network. This covers access through the following means:
Telnet and other terminal emulation applications
The switch’s web browser interface
SSH
SNMP versions 1, 2 and 3(with a correct community name)
TFTP
Also, when configured in the switch, the Authorized IP Managers feature takes
precedence over local passwords, TACACS+, RADIUS, Port-Based Access
Control (802.1X), and Port Security. This means that the IP address of a
networked management device must be authorized before the switch will
attempt to authenticate the device by invoking any other access security
features. If the Authorized IP Managers feature disallows access to the device,
then access is denied. Thus, with authorized IP managers configured, having
the correct passwords is not sufficient for accessing the switch through the
network unless the station attempting access is also included in the switch’s
Authorized IP Managers configuration.
You can use Authorized IP Managers along with other access security features
to provide a more comprehensive security fabric than if you use only one or
two security options.
Note When no Authorized IP manager rules are configured, the access method
feature is disabled, that is, access is not denied.
14-2
