10 permit tcp 10.30.133.27 0.0.0.0 eq 23 0.0.0.0 255.255.255.255

IPv4 Access Control Lists (ACLs)

Creating or Editing ACLs Offline

If you are replacing an ACL on the switch with a new ACL that uses the

same number or name syntax, begin the command file with a no ip access-

list command to remove the earlier version of the ACL from the switch’s

running-config file. Otherwise, the switch will append the new ACEs in

the ACL you download to the existing ACL. For example, if you planned

to use the copy command to replace ACL “List-120”, you would place this

command at the beginning of the edited file:

no ip access-list extended List-120

Removes an existing ACL

ip access-list extended "List-120"

and replaces it with a

10 remark "THIS ACE ALLOWS TELNET"

new version with the

same identity. To append

20 deny ip 10.30.133.1 0.0.0.255 0.0.0.0 255.255.255.255

new ACEs to an existing

ACL instead of replacing

30 deny ip 10.30.155.1 0.0.0.255 0.0.0.0 255.255.255.255

it, you would omit the first

40 remark "THIS IS THE FINAL ACE IN THE LIST"

line and ensure that the

40 permit ip 0.0.0.0 255.255.255.255 0.0.0.0 255.255.255.255

sequence numbering for

exit

the new ACEs begin with

a number greater than

the highest number in the

existing list.

Figure 9-32. Example of an Offline ACL File Designed To Replace An Existing ACL

3. Use copy tftp command-file to download the file as a list of commands to

the switch.

4. Use the show run or show access-list config command to inspect the switch

configuration to ensure that the ACL was properly downloaded.

Note If a transport error occurs, the switch does not execute the command and the

ACL is not configured.

9-95
