Component identification 11
Power interposer board components
12 LFF HDDs
Item
Description
1
Power connector (J1)
2
Power connector (J10)
3
Power connector (J11)
4
Power connector (J9)
5
Power connector (J13)
6
Signal connector (J17)
7
Power connector (J5)
8
Power connector (J6)
9
Power connector (J4)
10
PSU connector (J2, J3)
