Hardware options installation 78
Installing a processor
CAUTION: ESD protection must be worn during the procedure to avoid damaging the
components.
To install a processor:
1. Align the processor on the processor tray.
2. Align the marker (triangle) on the CPU carrier with the same marker located on the processor. The
protrusions on the CPU carrier are also aligned with the indentations on the processor when properly
aligned.
3. Press the CPU carrier to make sure it is locked with the processor.
