Hardware options installation 70
NVMe M.2 cards
Removing a NVMe M.2 card
To remove an NVMe M.2 card:
1. Power down the server and detach all of the power cords from the power supplies.
2. Remove the access panel (on page 31).
3. Remove the riser board (on page 54).
4. Remove the screw securing the NVMe M.2 card.
5. The card springs up. Grasp the NVMe M.2 card and remove.
