Hardware options installation 48
Air baffles
Removing an air baffle
CAUTION: To avoid damaging server components, do not use force when removing the air
baffle.
To remove an air baffle:
1. Power down the server and detach all power cords from the power supplies.
2. Remove the access panel (on page 31).
3. Remove the screws securing the air baffle and the chassis.
4. Gently lift the air baffle out of the chassis.
