Hardware options installation 49
Installing an air baffle
CAUTION: To avoid damaging server components, do not use force when removing the air
baffle.
Be sure all DIMM latches are locked to avoid damaging the components.
To install an air baffle:
1. To position the air baffle, see the following figure.
2. Lower the air baffle in the chassis.
3. Secure the air baffle and the chassis with screws.
4. Install the access panel (on page 31).
