Hardware options installation 31
3. Remove the SSD bracket from the SSD.
Access panels
Removing an access panel
CAUTION: Ensure that the server had been powered off and the AC power cords were
disconnected from the server power supplies.
To remove an access panel:
1. Power down the server and detach all power cords from the power supplies.
2. Loosen the thumb screw.
3. Slide and lift up the access panel from the chassis.
Installing an access panel
To install an access panel:
1. Align the access panel over the chassis.
2. Slide the access panel as shown in the following illustration.
3. Make sure the access panel is flush with the front of the chassis.
4. Secure the access panel and the chassis with the thumb screw.
