Hardware options installation 76
Processors
Passive heat sinks cool processors. To achieve optimal cooling performance, TIM must be installed
between the processor and heat sink. The mechanical performance of the heat sink is designed to meet
the requirements of Intel processors. The heat sink is necessary to maintain chipset temperature at or
below temperature limits.
Removing a processor
CAUTION: ESD protection must be worn during the procedure to avoid damaging the
components.
To remove a processor:
1. Power down the server and detach all of the power cords from the power supplies.
2. Remove the access panel (on page 31).
3. Remove the air baffle (on page 48).
4. Sequentially loosen the screws on the heat sink.
5. Lift up the processor assembly (heat sink, processor and CPU carrier) to remove.
