Hardware options installation
67
Installing
an
OCP mezzanine card
To install an OCP mezzanine card:
1.
Align the connector on the OCP me
zzanine card with the slot on the system board.
2.
Install the OCP mezzanine card gently
.
3.
Secure the OCP mezzanin
e card to the chassis with screws.
4.
Install the access panel (on page
31
).
66
68
