Specifications 196
Specifications
Environmental specifications
10°C to 35°C (50°F to 95°F)
-30°C to 60°C (-22°F to 140°F)
Relative humidity
(Non-condensing)
Minimum to be the higher (more moisture) of -12°C (10.4°F) dew
point or 8% relative humidity
Maximum to be 28°C (82.4°F) dew point or 90% relative
humidity
5% to 95%
38.7°C (101.7°F), maximum wet bulb temperature
* All temperature ratings shown are for sea level. An altitude derating of 1.0°C per 305 m (1.8°F per 1,000 ft) to
3050 m (10,000 ft) is applicable. No direct sunlight allowed. Maximum rate of change is 20°C per hour (36°F per
hour). The upper limit and rate of change might be limited by the type and number of options installed.
Mechanical specifications
