hpmont HD5L-PLUS Series User Manual

Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd.
100 HD5L-PLUS Series User Manual V1.0
Ref. Code
Function Setting Range Default Unit
Attribute
Setting
F04: Analog Curve Parameters (on page 53 - 53)
F04.00 Setting curve
Unit: AI characteristic curve
selection
Ten, hundred, thousand:
Unused
0: Line 1
1: Line 2
0000 1
×
F04.01 Line 1 min. setting 0.0% - F04.03 0.0% 0.1%
○
F04.02
Corresponding value of line 1
min. setting
0.0 - 100.0% 0.0% 0.1%
○
F04.03 Line 1 max. setting F04.01 - 100.0% 100.0% 0.1%
○
F04.04
Corresponding value of line 1
max. setting
0.0 - 100.0% 100.0% 0.1%
○
F04.05 Line 2 min. setting 0.0% - F04.07 0.0% 0.1%
○
F04.06
Corresponding value of line 2
min. setting
0.0 - 100.0% 0.0% 0.1%
○
F04.07 Line 2 max. setting F04.05 - 100.0% 100.0% 0.1%
○
F04.08
Corresponding value of line 2
max. setting
0.0 - 100.0% 100.0% 0.1%
○
F05: Speed Parameters (on page 53 - 55)
F05.00 Multi-speed 0 0.000m/s - F00.02 0.000m/s 0.001m/s
○
F05.01 Multi-speed 1 0.000m/s - F00.02 0.000m/s 0.001m/s
○
F05.02 Multi-speed 2 0.000m/s - F00.02 0.000m/s 0.001m/s
○
F05.03 Multi-speed 3 0.000m/s - F00.02 0.000m/s 0.001m/s
○
F05.04 Multi-speed 4 0.000m/s - F00.02 0.000m/s 0.001m/s
○
F05.05 Multi-speed 5 0.000m/s - F00.02 0.000m/s 0.001m/s
○
F05.06 Multi-speed 6 0.000m/s - F00.02 0.000m/s 0.001m/s
○
F05.07 Multi-speed 7 0.000m/s - F00.02 0.000m/s 0.001m/s
○
F05.08 Inspection running speed 0.000m/s - F00.02 0.200m/s 0.001m/s
○
F05.09 Emergency running speed 0.000m/s - F00.02 0.100m/s 0.001m/s
○
F05.10
Up forced speed switch
detection value
0.0 - 100.0% (F00.02) 97.0% 0.1%
○
F05.11
Down forced speed switch
detection value
0.0 - 100.0% (F00.02) 97.0% 0.1%
○
F05.12
Speed detection level 1
(FDT1)
0.0 - 100.0% (F00.02) 90.0% 0.1%
○
F05.13
Speed detection level 2
(FDT2)
0.0 - 100.0% (F00.02) 90.0% 0.1%
○
F05.14 FDT1 delay level 0.0 - 100.0% (F00.02) 1.0% 0.1%
○
F05.15 FDT2 delay level 0.0 - 100.0% (F00.02) 1.0% 0.1%
○
F05.16 Speed within FAR range 0.0 - 20.0% (F00.02) 1.0% 0.1%
○
F05.17 Over-speed setting 80.0 - 120.0% (F00.02) 115.0% 0.1%
×
F05.18 Over-speed detection time
0.0 - 2.0s
0.0: No over-speed detection
0.2s 0.1s
×
