Shenzhen Hpmont Technology Co., Ltd. Appendix A Parameters
HD5L-PLUS Series User Manual V1.0 101
Function
Setting Range Default
Unit
Setting
F05.19
Detected value of speed
deviation
0.0 - 30.0% (F00.02) 20.0% 0.1%
×
F05.20
Detected time of speed
deviation
0.0 - 2.0s
0.0: No speed deviation detection
1.0s 0.1s
×
F05.22 Creeping speed 0.000 - 0.400m/s 0.050m/s 0.001m/s
○
F06: Weighing Compensation Parameters (on page 55 - 56)
F06.00 Pre-torque selection
0: No pre-torque
1: Analog setting
2: DI setting
3: Digital pre-torque
4: No weighing auto-
compensation
5: Asyn. motor zero-serve auto-
compensation
4 1
×
F06.01 Up pre-torque bias 0.0 - 100.0% 50.0% 0.1%
×
F06.02 Down pre-torque bias 0.0 - 100.0% 50.0% 0.1%
×
F06.03 Up electrical pre-torque gain 0.000 - 9.000 1.000 0.001
×
F06.04 Up brake pre-torque gain 0.000 - 9.000 1.000 0.001
×
F06.05
Down electrical pre-torque
gain
0.000 - 9.000 1.000 0.001
×
F06.06 Down brake pre-torque gain 0.000 - 9.000 1.000 0.001
×
F06.07 Pre-torque digital setting -100.0 - +100.0% 10.0% 0.1%
×
F06.08 DI weighing signal 1 0.0 - 100.0% 10.0% 0.1%
×
F06.09 DI weighing signal 2 0.0 - 100.0% 30.0% 0.1%
×
F06.10 DI weighing signal 3 0.0 - 100.0% 70.0% 0.1%
×
F06.11 DI weighing signal 4 0.0 - 100.0% 90.0% 0.1%
×
F06.14
No weighing current
coefficient
0 - 9999 3000 1
×
F06.15 No weighing speed-loop KP 1 - 9999 2000 1
○
F06.16 No weighing speed-loop KI 1 - 9999 2000 1
○
F07: Asyn. Motor Parameters (on page 56 - 59)
F07.00 Rated power of Asyn. motor 0.2 - 500.0kW
Depend
on HD5L-
PLUS
0.1kW
×
F07.01 Rated voltage of Asyn. motor 0V - rated voltage of HD5L-PLUS 1V
×
F07.02 Rated current of Asyn. motor 0.0 - 999.9A 0.1A
×
F07.03
Rated frequency of Asyn.
motor
1.00 - 100.00Hz 50.00Hz 0.01Hz
×
F07.04 Rated Rpm of Asyn. motor 1 - 24000rpm 1440rpm 1rpm
×
F07.05 Power factor of Syn. motor 0.001 - 1.000
Depend
on HD5L-
PLUS
0.001
×
To Next Page
