Ref. Code
Function Setting Range Default Unit
Attribute
Setting
F07.06
Parameter auto-tuning of
Asyn. motor
0: No action
1: Auto-tuning with load
2: Auto-tuning without load
0 1
×
F07.07
Stator resistance of Asyn.
motor
0.000 - 65.355Ω
Depend
on HD5L-
PLUS
0.001Ω
×
F07.08
Rotor resistance of Asyn.
motor
0.000 - 65.535Ω 0.001Ω
×
F07.09
Leakage inductance of Asyn.
motor
0.0 - 6553.5mH 0.1mH
×
F07.10
Mutual inductance of Asyn.
motor
0.0 - 6553.5mH 0.1mH
×
F07.11
Excitation current of Asyn.
motor
0.0 - 999.9A 0.1A
×
F07.12
Core saturation coefficient 1
of Asyn. motor
0.00 - 0.50 (magnetic flux is set
as 50%)
0.50 0.01
×
F07.13
Core saturation coefficient 2
of Asyn. motor
0.00 - 0.75 (magnetic flux is set
as 75%)
0.75 0.01
×
F07.14
Core saturation coefficient 3
fo Asyn. motor
0.00 - 1.20 (magnetic flux is set
as 120%)
1.20 0.01
×
F07.15 Asyn. motor torque boost 0.1 - 30.0% 0.1% 0.1%
○
F07.16
Torque boost end-point of
Asyn. motor
0.0 - 50.0% (F07.03) 2.0% 0.1%
○
F07.17
Slip compensation gain of
Asyn. motor
0.0 - 300.0% 100.0% 0.1%
○
F07.18
Slip compensation filter time
of Asyn. motor
0.1 - 10.0s 0.1s 0.1s
○
F07.19
Slip compensation limit of
Asyn. motor
0.0 - 250.0% 200.0% 0.1%
×
F07.20
AVR (Automatic Voltage
Regulation) function
0: Disabled
1: Enabled the time
2: Disabled in Dec. speed
1 1
○
F07.21
Oscillation-suppression mode
of Asyn. motor
0: Oscillation suppression is
dependent on the motor’s
exciting current component
1: Oscillation suppression is
dependent on the motor’s
torque current component
0 1
○
F07.22
Oscillation-suppression
coefficient of Asyn. motor
0 - 200 100 1
○
F08: Motor Vector Control Speed-loop Parameters (on page 59 - 60)
F08.00 Low speed ASR KP 1 - 9999 500 1
○
F08.01 Low speed ASR KI 0 - 9999 500 1
○
F08.02 High speed ASR KP 1 - 9999 500 1
○
F08.03 High speed ASR KI 0 - 9999 500 1
○
F08.04 ASR PI swithcing frequency 1 0.00 - 50.00Hz 10.00Hz 0.01Hz
○
