Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd.
106 HD5L-PLUS Series User Manual V1.0
Function
Setting Range Default
Unit
Setting
F12.05 DI5 function
9: Contactor feedback input
(CSM)
10: Brake feedback input (BSM)
11 - 14: Weighing input
1 - 4 (WD1 - WD4)
15: Motor overheat input (OH)
16: Fault reset input (RST)
17: Up forced speed input (UPF)
18: Down forced speed input
(DNF)
19: Governor feedback input
(OSG)
20 - 33: Unused
34: External fault (EXT)
Hundred digit = 0, normally open
input selected; = 1, normally
closed input selected
5 1
×
F12.06 DI6 function 6 1
×
F12.07 DI7 function 0 1
×
F12.08 DI8 function 0 1
×
F12.09 DI9 function 0 1
×
F12.10 DI10 function 0 1
×
F12.11 DI11 function 0 1
×
F12.12 DI12 function 0 1
×
F12.13
Filter time of multi-speed
terminal
0.000 - 2.000s 0.010s 0.001s
×
F12.15 DO1 function
0: Unused
1: Controller is ready
2: Controller is in running
3: Zero-speed running
4: Zero-speed
5: Contactor output control
6: Brake output control
7: Speed level detection signal 1
(FDT1)
8: Speed level detection signal 2
(FDT2)
9: Speed arrival signal (FAR)
10: Up signal output
11: Down signal output
12: Under-voltage
13: Unused
14: Controller fault
15: Elevator stop
16 - 19: Unused
20: Speed outputs
21: Advanced door open signal
output
2 1
×
F12.16 DO2 function 3 1
×
F12.17 Y1 function 14 1
×
F12.18 Y2 function 0 1
×
F12.19 Y3 function 0 1
×
F12.20 Y4 (RLY ) function 0 1
×
F12.21 Output terminal logic setting
Bit0, Bit1: DO1, DO2
Bit2 - Bit5: Y1 – Y3, Y4 (RLY )
0: Positive logic
1: Negative logic
00 1
○
To Next Page
