hpmont HD5L-PLUS Series - Page 121

Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd.
110 HD5L-PLUS Series User Manual V1.0
Ref. Code
Function Setting Range Default Unit
Attribute
Setting
F16: Function-boost Parameters (on page 69 - 70)
F16.00
Zero-speed running signal
delay time
0.00 - 10.00s 0.30s 0.01s
×
F16.01 Zero-speed signal delay time 0.00 - 10.00s 0.30s 0.01s
×
F16.02 Current keep time after stop 0 - 9999ms 300ms 1ms
×
F16.03 Fan control mode
0: Auto stop
1: Immediately stop
2: Run when power on
0 1
○
F16.04 Fan control delay time 0.0 - 600.0s 30.0s 0.1s
○
F16.05 Brake unit action voltage
220V: 380 - 450V
380V: 630 - 750V
Depend
on HD5L-
PLUS
1V
×
F16.06 Contactor fault detect time 0.1 - 10.0s 2.0s 0.1s
×
F16.07 Multi-speed inspection 0 - 7 0 1
×
F16.08 Zero speed threshold 0.001 - 0.010m/s 0.003m/s 0.001m/s
○
F16.09
Selection at motor overheat
fault
0: Alarms E20 fault after motor
stops
1: Alarms E20 fault at once
0 1
○
F16.11
Running current limit of Syn.
motor auto-tuning with load
20 - 200% 120% 1%
×
F16.12
Delay time of run output
signal
0.00 - 1.00s 0.00s 0.01s
×
F16.13
UPS running direction auto -
determine enable
0: Not enable
1: The current judges the
running direction
2: The encoder direction judges
the running direction
3: The current judges the
running direction (without start
compensation and zero speed
hold)
4: The encoder direction judges
the running direction (without
start compensation and zero-
speed hold)
0 1
×
F16.14 Running min. current limit 0 - 100% (F07.11) 20% 1%
×
F16.15 Running min. detect time 0.0 - 5.0s 0.0s 0.1s
×
F16.16 Governor fault detection time 0.0 - 2.0s 1.0s 0.1s
×
F16.17 DC braking current at stop 0 - 150% 100% 1%
×
F16.18
Starting frequency of DC
braking current at stop
0.20 - 10.00Hz 0.50Hz 0.01Hz
×
F16.19 Brake release frequency 0.00 - 10.00Hz 0.00Hz 0.01Hz
×
