hpmont HD5L-PLUS Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Appendix A Parameters
HD5L-PLUS Series User Manual V1.0 111
Ref. Code
Function Setting Range Default Unit
Attribute
Setting
F17: Fault Protect Parameters (on page 70 - 72)
F17.00
Input voltage at motor
overheat
0.00 - 10.00V 0.00V 0.01V
×
F17.01
Motor overheat analog signal
input type
0: Not detect
1: Positive charateristic (PTC)
2: Negative charateristic (NTC)
0 1
×
F17.03
The detection base of lack of
input
0 - 100% (rated voltage of
controller)
30% 1%
×
F17.04
The detection time of lack of
input
0.0 - 5.0s 1.0s 1.0s
×
F17.05
The detection base of lack of
output
0 - 100% (rated current of
controller)
20% 1%
×
F17.06
The detection time of lack of
output
0.0 - 20.0s 3.0s 1.0s
×
F17.07 Motor overload protect factor 20.0 - 110.0% 100.0% 1.0%
×
F17.08 Fault auto restet times
0 - 100
0: No auto reset function
0 1
×
F17.09 Fault auto reset interval 2.0 - 20.0s/time 5.0s/time 0.1s/time
×
F17.10 Faulty relay action
Unit: In auto reset process
Ten: In undervoltage process
0: Doesn’t act
1: Acts
00 1
○
F17.11 NO.5 fault type
Lu: DC bus undervoltage
E01: Acc. overcurrent
E02: Dec. overcurrent
E03: Constant speed
overcurrent
E04: Acc. overvoltage
E05: Dec. overvoltage
E06: Constant speed
overvoltage
E08: Power module fault
E09: Heatsink overheat
E10: Braking unit fault
E11: CPU fault
E12: Motor auto-tuning fault
E13: The power-on buffer
contactor is not closed
E14: Current detection fault
E15: Input voltage phase loss
E16: Output voltage phase loss
E17: Controller overload
E18: Excessive speed deviation
E19: Motor overload
0 1 *
A
