Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd.
112 HD5L-PLUS Series User Manual V1.0
Ref. Code
Function Setting Range Default Unit
Attribute
Setting
E20: Motr overheat
E21: Read/Write fault of control
borad EEPROM
E22: Read/Write fault of keypad
EEPROM
E23: Faulty setting of parameter
E24: Fault of external equipment
E25: Too small running current
E26: Internal logic error
E28: SCI communication
timeout
E29: SCI communication error
E30: Encoder reverse
E31: Encoder disconnection
E32: Motor over speed
E33: Z signal loss of ABZ
encoder
E34: UVW signal wrong of UVW
encoder
E35: CD phase wrong of SINCOS
encoder
E36: Contactor fault
E37: Governor fault
E08, E10, E13, E14, E21, E22, E24,
E36 can’t auto reset
F17.12 Setting freqency at NO.5 fault 0.00 - 100.00Hz 0.00Hz 0.01Hz *
F17.13 Output freqency at NO.5 fault 0.00 - 100.00Hz 0.00Hz 0.01Hz *
F17.14 DC bus vlotage at NO.5 fault 0 - 999V 0V 1V *
F17.15 Output voltage at NO.5 fault 0 - 999V 0V 1V *
F17.16 Output current at NO.5 fault 0.0 - 999.9A 0.0A 0.1A *
F17.17
Input terminal status at NO.5
Fault
0 - 0x1FF 0 1 *
F17.18
Output terminal status at
NO.5 fault
0 - 0x3F 0 1 *
F17.19 NO.5 fault interval 0.0 - 6553.5h 0.0h 0.1h *
F17.20 NO.4 fault type 0 - 36 0 1 *
F17.21 NO.4 fault interval 0.0 - 6553.5h 0.0h 0.1h *
F17.22 NO.3 fault type 0 - 36 0 1 *
F17.23 NO.3 fault interval 0.0 - 6553.5h 0.0h 0.1h *
F17.24 NO.2 fault type 0 - 36 0 1 *
F17.25 NO.2 fault interval 0.0 - 6553.5h 0.0h 0.1h *
F17.26 NO.1 fault type 0 - 36 0 1 *
F17.27 NO.1 fault interval 0.0 - 6553.5h 0.0h 0.1h *
