hpmont HD5L-PLUS Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Appendix A Parameters
HD5L-PLUS Series User Manual V1.0 113
Ref. Code
Function Setting Range Default Unit
Attribute
Setting
F18: PWM Parameters (on page 72 - 73)
F18.00 Carrier fregency 1 - 16kHz
Depend
on HD5L-
PLUS
1kHz
×
F18.01
Carrier freqency auto adjust
selection
0: Prohibited
1: Allowed
0 1
×
F18.02 PWM overmodulation enable
0: Disable
1: Enable
1 1
×
F18.03 PWM overmodulation mode
0: Two phase and three phase
swtich
1: Three phase
0 1
×
F19: Enhance Parameters ( on page 73 - 75)
F19.43
Optimize 1313 encoder CD
signal
0: Not optimized
1: Optimize
0 1
×
F19.44 SVC5 control selection
0: Normal processing
1: Optimized processing
1 1
×
F19.45
Hardware circuit detection
method
0: Sample 1
1: Sample 2
0 1
×
F19.46 SVC flux cutoff frequency 0.30 - 3.00Hz 0.50Hz 0.01Hz
×
F19.47
SVC velocity estimation filter
coefficients
0: 8
1: 16
2: 32
0 1
×
F19.48
SVC velocity observation
period
0: 1ms
1: Interrupt
0 1
×
F19.49 SVC no-load current boost
0: Boost
1: Not boost
0 1
×
F19.50
SVC5/SVC6 low-speed
variable carrier enable
0: Unable
1: Enable
0 1
×
F19.51
Motor overload protection
percentage
120 - 200% 170% 1%
×
F19.52
Motor overload protection
time
0 - 3: Not work.
4 - 10: Protect.
5s 1s
×
F19.53
Modify the no-load current to
automatically update the
mutual inductance value
0: Auto change
1: Do not change automatically
0 1
×
F19.54
Maintenance operation
command to remove the
processing method
0: Downtime processing
1: Switch to multi-speed
operation
0 1
×
F19.55
Electric and power generation
slip compensation gain
compensation enable
respectively
0: Unable
1: Enable
0 1
×
F19.56
Electric slip compensation
gain
20.0 - 200.0% 100.0% 0.1%
×
A
