Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd.
114 HD5L-PLUS Series User Manual V1.0
Function
Setting Range Default
Unit
Attribute
Setting
F19.57
Power generation slip
compensation gain
20.0 - 200.0% 100.0% 0.1%
×
F19.58
Allow the speed setting to exceed
the rated speed of the motor
0: Not allow
1: Allow
0 1
×
F19.63
Starting DC current for
emergency operation
50 - 100% 70% 1%
×
F19.64
Starting DC braking time of
emergency operation
0.0 - 3.0s 0.0s 0.1s
×
F19.65
DC current of emergency
operation shutdown
50 - 100% 70% 1%
×
F19.66
DC braking time of emergency
operation shutdown
0.0 - 3.0s 1.5s 0.1s
×
F19.67
Emergency operation current
search torque limit
40.0 - 200.0% 100.0% 0.1%
×
F19.68
Emergency operation torque
increase
0.1 - 30.0% 0.1% 0.1%
×
F19.69
Cut off point for emergency
operation torque raising
0.1 - 50.0% (rated motor
frequency)
25.0% 0.1%
×
F19.70
Emergency operation V/F output
rated voltage percentage
60.0 - 100.0% 100.0% 0.1%
×
F19.71 Open short floor function
0: Not open
1: Open
0 1
×
F19.72 Virtual speed running time 0.0 - 3.0s 0.0s 0.1s
×
F19.73 Virtual speed 0.000 - 1.500 m/s 1.000m/s 0.001m/s
×
F19.74
High speed multi terminal speed
setting
0 - 7 0 1
×
F19.75
Multi speed setting of creeping
speed
0 - 7 0 1
×
F19.77
Enable abnormal judgment of CD
phase auto-tuning process of
SINCOS encoder
0: Check the CD signal.
1: Does not detect.
0 1
×
F19.78
Safety gear unlocking mode
power level limit
0: The HD5L-PLUS shall have
at least one power level of
large motor, F19 79 works
1: F19.79 is not limited by
power (use with caution)
0 1
×
F19.79 Safety gear unlocking mode
0: Not turn on unlocking
mode
1: Open unlocking mode 1
2: Open unlocking mode 2
3: Open unlocking mode 3
0 1
×
F19.80 Safety gear unlocking duration 0 - 10s 5s 1s
×
F19.81
Safety gear unlocking mode stop
time
0 - 5min 2min 1min
×
F19.82
Safety gear unlocking continuous
maximum torque current setting
200 - 300% (rated motor
current)
220% 1%
×
