hpmont HD5L-PLUS Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Appendix A Parameters
HD5L-PLUS Series User Manual V1.0 115
Ref. Code
Function Setting Range Default Unit Attribute Setting
F19.88 SVC6 I/F control enable
0: Unable
1: Enable
1 1
×
F19.89
SVC6 I/F control frequency cutoff
point
2.00 - 10.00Hz 4.00Hz 0.01Hz
×
F19.90 SVC6 I/F control torque given 0 - 200Hz 100Hz 1Hz
×
F19.91 Maintenance password 0 - 65535 53214 1
×
F19.92
Maintenance function activation
option
0: Not activated.
1: Activating the
maintenance function and
shutting down due to
failure.
0 1
×
F19.93 Maintenance method
0: Invalid.
1: According to the number
of runs.
2: According to the power-
on time
0 1
×
F19.94 Maintenance times 0 - 65535 20000 1
×
F19.95 Maintenance set power-on time 0 - 2700 days 90 days 1 day
×
F19.96
SVC6 IF control transition
optimization
0: Normal processing
1: Optimized processing
1 1
×
F19.98 SVC5 start processing 1 1
×
F20: Enhance Parameter Group 2 (on page 75)
F20.00 Start DC braking current 50 - 150% 100% 1%
×
F20.01
Start DC brake current duratiion
time
0.0 - 3.0s 0.0s 0.1s
×
F20.02 DI enable function
0: Original plan
1: New plan
0 1
×
F20.03 Output contactor opening time 0 - 9s 0s 1s
×
F20.04
Output ground detection before
operation
0: Detect
1: Not detected
0 1
×
F20.05
Encoder C, D disconnection
detection
0 1
×
F20.06 Speed control proportional gain 1 1 - 100 30 1
○
F20.07 Speed control integration time 1 0.01 - 10.00s 0.50s 0.01s
○
F20.08 Speed control proportional gain 2 1 - 100 20 1
○
F20.09 Speed control integration time 2 0.01 - 10.00s 1.00s 0.01s
○
F20.10
Static self-tuning method for
identifying no-load current
0: Calculated according to
power factor
1: Estimated based on pole
logarithmic power
0 1
×
F20.11 Open door speed threshold 0.00 - 0.250m/s 0.100m/s 0.001m/s
○
F20.12
Output delay time after early
door open relay output shutdown
0 - 3000ms 500ms 1ms
○
A
