hpmont HD5L-PLUS Series User Manual

Chapter 5 Operation Instructions Shenzhen Hpmont Technology Co., Ltd.
40 HD5L-PLUS Series User Manual V1.0
Table 5-4 Switching four-level description of the key
Key First-level Menu Second-level Menu Third-level Menu Fourth-level Menu
PRG
Fault, return to fault
display; Fault cleared,
return to run or stop
status display
Return to first-level
menu
Return to second-level
menu
Do not save the present
value and return to
third-level
Enter to second-level
menu
Enter to third-level menu Enter to fourth-level menu
Save the present value
and return to third-level
Select function
group.
Cycle according to
D-F-Y
Modify No. function.
Increase by 1 when press
this key one time
Modify the parameter.
Increase by 1 according to
the present modified bit
Modify function value.
Increase by 1 according
to the present modified
bit
Select function
group.
Cycle according to
Y-F-D
Modify No. function.
Decrease by 1 when
press this key one time
Modify the parameter.
Decrease by 1 according
to the present modified
bit
Modify function value.
Decrease by 1 according
to the present modified
bit
Invalid Invalid Switch unit and ten
Switch unit, ten
thousand, thousand,
hundred, ten
Setting Parameter
For example: To modify F00.07 from 1.500m/s to 1.000m/s, as shown in Figure 5-5.
Figure 5-5 Parameter setting
In the fourth level menu, if the parameter does not flash, it means that the parameter cannot be
modified. The possible reasons are as follows:
• The parameter can’t be modified, such as the actual detected parameters, running record
parameters, etc.
• Only when the controller stops can the function parameter be modified in running status.
• Only input the correct password can it edit the function parameter due to the valid password.
Se
cond
-leve
l me
nu
F
irst
-lev
el me
nu
St
op st
atu
s
M
odif
y th
e set
valu
eThird
-le
vel m
enu
Shi
ftFo
urt
h-le
vel m
enuT
hird-
level
men
u
P
RG
PR G
PR
G
