The supported device types are IEC103 device 1 to IEC103 device 5. The
corresponding conguration le names are iec103_equip_custom_1.cfg to
iec103_equip_custom_5.cfg. Multiple devices of the same type can be connected.
Step 1 Congure a protocol information point le in .cfg format and import the le to
the SmartLogger.
Figure 6-57 Importing
conguration
Step 2 Set access parameters and click Add Devices.
Figure 6-58 Setting access parameters
Parameter Description
Device Type The value can be IEC103 Device 1 to IEC103 Device
5.
Select a value based on the conguration le. For
example, if iec103_equip_custom_1.cfg needs to be
imported, select IEC103 Device 1.
Port number Set this parameter to the COM port connected to the
IEC103 device.
Address Set this parameter to the communication address of
the IEC103 device.
Step 3 Set device monitoring parameters and click Submit.
SmartLogger3000
User Manual 6 WebUI Operations
Issue 10 (2022-08-20) Copyright © Huawei Technologies Co., Ltd. 182
