Huawei SmartLogger3000 User Manual

The cosφ-P/Pn characteristic curve control mode is to dynamically adjust the
power factor cosφ in accordance with the P/Pn (%) based on the VDE-4105 and
BDEW German standards.
Parameter Description
Reactive power control
mode
Set this parameter to cosφ-P/Pn characteristic curve.
Reactive power
adjustment time
Species the change interval of the reactive power at
the grid-connection point.
Characteristic curve
points
Species the number of points on the characteristic
curve.
The characteristic curve supports a maximum of 10
valid points.
U/Un(%) When conguring the curve, ensure that the P/Pn(%)
value of a point is greater than the P/Pn(%) value of
the previous point. Otherwise, the message indicating
invalid input will be displayed.
cosφ
Q-U Hysteresis Curve (CEI0-16)
If you do not need the SmartLogger to send remote reactive power control
commands, you can congure the characteristic curve as a substitute. The
SmartLogger delivers the values congured for the characteristic curve to the solar
inverter or Smart PCS, which then operates according to the
conguration. The
SmartLogger no longer adjusts the values.
NO TICE
Congure the characteristic curve under instructions from professionals to ensure
that the solar inverter or Smart PCS works properly.
The Q-U hysteresis curve (CEI0-16) control mode is the Italian standard CEI0-16
version of the Q-U characteristic curve. It dynamically adjusts the output reactive
power of the solar inverter in accordance with the ratio of the actual voltage to
the rated voltage. The
nal value should be in the form of Q/S.
Parameter
Description
Reactive power control
mode
Set this parameter to Q-U hysteresis curve(CEI0-16).
Reactive power
adjustment time
Species the change interval of the reactive power at
the grid-connection point.
SmartLogger3000
User Manual 6 WebUI Operations
Issue 10 (2022-08-20) Copyright © Huawei Technologies Co., Ltd. 213
