Table 3-15 lists the IEN1000 CPA03 upgrade module’s interface specifications:
Table 3-15 CPA03 Interface Specifications
Note: Refer to Chapter 4, Cable Specifications & Adapters for more information about these and
other Hypercom cables.
Local Ports (3)
Three RS232/V.24 (56Kbps Max) or one V.35 (2048Kbps) and two RS232/
V.24 ports.
Protocols
SDLC/SNA
SDLC
SDLC group poll / full duplex
SDLC to LLC2 conversion
X.25
BSC 3270 and BSC 2780/3780
Burroughs Poll Select
ASYNC
X.3 PAD/X.28
Cables
n
Type D cross cable used to provide RS232 DCE female
interface from IEN 1000
n
Type A straight male-to-male RS232 cable used to attach the
IEN 1000 to external devices
n
Type VX cross cable used to provide V.35 DCE male interface
from the IEN 1000
n
Type VE adapter cable used to provide V.35 DTE male interface
from the IEN 1000
n
Type VF adapter cable used to provide V.35 DTE female
interface from the IEN 1000
