SYSTEM CONFIGURATION
940043-002 INTEGRATED ENTERPRISE NETWORK 6-9
Serial
Ports
The Serial Ports area displays the operational status of the base IEN 1000 serial port 1, and
the status of the optional serial ports 2 through 4. Refer to CHAPTER 3, CPA03 for more
information about the CPA03 upgrade module. The Serial Port status contains the following
valid values:
C
The circuit is connected.
A
The circuit is not connected.
Dial Port
The Dial Port area contains the following valid values:
R
The optional Dial Backup Unit is installed.
K
The base IEN 1000 internal V.22 modem is installed.
LAN Port
The LAN Port area indicates whether an optional LAN interface module is installed. The IEN
1000 may contain the LET10 Ethernet or LTR10 Token Ring optional upgrade module. The
LAN Port status contains the following valid values:
Ethernet
Refer to CHAPTER 3, LET10 for more information about the LET10 upgrade
module.
C
The circuit is connected.
0
The circuit is not connected.
A
The circuit is not connected.
Token
Ring
Refer to CHAPTER 3, LTR10 for more information about the LTR10 upgrade
module.
0
Indicates normal system start-up: No ring connection.
A
Received configuration table from NMS.
2
Ring insertion in progress (waiting for ring connection).
C
Indicates a ring insertion.
L
Indicates a lobe wire fault.
F
Indicates a failure to insert in the ring.
