PORT PROCESSORS/MODULES
940043-002 INTEGRATED ENTERPRISE NETWORK 3-7
Figure 3-5 illustrates the bus communications for the CID15H/CID15H-A port processor.
Figure 3-5 CID15H/CID15H-A Bus Communications
Figure 3-6 illustrates the jumper locations on the CID15H/CID15H-A port processor.
Figure 3-6 CID15H/CID15H-A Jumper Locations
