Hypertherm Powermax30 AIR Service Manual

20 Powermax30 AIR Service Manual 808850
1 – Specifications
Torch dimensions
Torch weight
 Air T30 torch with consumables only: 0.3 kg (0.65 pounds)
 Air T30 torch with consumables and 4.6 m (15 foot) lead (with strain relief): 1.0 kg (2.25 pounds)
25 mm
(1.0 inch)
51 mm (2.0 inches)
230 mm (9.0 inches)
45 mm
(1.8 inches)
86 mm
(3.4 inches)
75°

Hypertherm Powermax30 AIR Specifications

General

Built-in Air Compressor	Yes
Output Voltage	83 VDC
Input Voltage	120-240 V
Current Output	15–30 A
Cutting Thickness	Up to 10 mm (3/8 in) recommended cut
Gas Supply	Built-in air compressor
Operating Temperature	-10°C to +40°C (+14°F to +104°F)
