Hypertherm Powermax30 AIR Service Manual

Powermax30 AIR Service Manual 808850 201
Section 8
Parts
Use the part numbers and kit numbers in this section to order consumables, accessories, and replacement parts for your
power supply and hand torch.
You can find procedures explaining how to install these kits in:
 Power Supply Component Replacement on page 97
 Torch Component Replacement on page 185

For instructions on installing the consumables in the hand torch, see Step 1 – Install the
consumables on page 43.

Hypertherm Powermax30 AIR Specifications

General

Built-in Air Compressor	Yes
Output Voltage	83 VDC
Input Voltage	120-240 V
Current Output	15–30 A
Cutting Thickness	Up to 10 mm (3/8 in) recommended cut
Gas Supply	Built-in air compressor
Operating Temperature	-10°C to +40°C (+14°F to +104°F)
