Hypertherm Powermax30 AIR Service Manual

Powermax30 AIR Service Manual 808850 41
Section 4
Operation
Controls and indicators
Familiarize yourself with the controls and LED indicators on the system before you begin cutting.
Rear controls
ON (I) / OFF (O) power switch
Activates the system and its control circuits.
O
O

Hypertherm Powermax30 AIR Specifications

General

Built-in Air Compressor	Yes
Output Voltage	83 VDC
Input Voltage	120-240 V
Current Output	15–30 A
Cutting Thickness	Up to 10 mm (3/8 in) recommended cut
Gas Supply	Built-in air compressor
Operating Temperature	-10°C to +40°C (+14°F to +104°F)
