Powermax30 AIR Service Manual 808850 39
3 – Torch Setup
120 V / 20 A cutting
Metric
Material thickness (mm) Material Arc current (A)
Maximum cut speed
(mm/minute)
1
Mild steel 20
6,540
2 2,420
3 1,245
4* 680
6* 400
8* 235
10* 90
1
Stainless steel 20
3,295
2 2,140
3 1,270
4* 965
5* 660
7* 150
1
Aluminum 20
5,500
2 3,610
3 1,720
4* 1,030
5* 740
7* 165
* To cut material thicker than 3 mm (10 gauge) at 120 V, start the torch at the edge of the workpiece.
