Hypertherm Powermax30 AIR Service Manual

44 Powermax30 AIR Service Manual 808850
4 – Operation
Step 2 – Connect the electrical power
Plug in the power cord.
See also
 For information on connecting the proper plug to the power cord, see Power cord considerations on page 29.
 To understand what cutting capacity to expect based on input voltage, see Consumable use on page 35.
 For information on electrical requirements for this system, see Power Supply Setup on page 25.

Hypertherm Powermax30 AIR Specifications

General

Built-in Air Compressor	Yes
Output Voltage	83 VDC
Input Voltage	120-240 V
Current Output	15–30 A
Cutting Thickness	Up to 10 mm (3/8 in) recommended cut
Gas Supply	Built-in air compressor
Operating Temperature	-10°C to +40°C (+14°F to +104°F)
