Hypertherm Powermax30 AIR Service Manual

Powermax30 AIR Service Manual 808850 219
Section 9
Wiring Diagrams
This section contains the following diagrams:
 Process flow for troubleshooting internal compressor and temperature fault LEDs
 Timing chart for torch start
 Powermax30 AIR schematic

Hypertherm Powermax30 AIR Specifications

General

Built-in Air Compressor	Yes
Output Voltage	83 VDC
Input Voltage	120-240 V
Current Output	15–30 A
Cutting Thickness	Up to 10 mm (3/8 in) recommended cut
Gas Supply	Built-in air compressor
Operating Temperature	-10°C to +40°C (+14°F to +104°F)
