Hypertherm Powermax30 AIR Service Manual

40 Powermax30 AIR Service Manual 808850
3 – Torch Setup
English
Material thickness
(gauge/inches)
Material Arc current (A)
Maximum cut speed
(inches/minute)
18 gauge
Mild steel 20
220
14 gauge 100
10 gauge 30
1/4* 14
3/8* 5
18 gauge
Stainless steel 20
120
14 gauge 89
12 gauge 54
1/4* 10
1/32
Aluminum 20
231
1/16 170
1/8 49
1/4* 14
* To cut material thicker than 3 mm (10 gauge) at 120 V, start the torch at the edge of the workpiece.

Hypertherm Powermax30 AIR Specifications

General

Built-in Air Compressor	Yes
Output Voltage	83 VDC
Input Voltage	120-240 V
Current Output	15–30 A
Cutting Thickness	Up to 10 mm (3/8 in) recommended cut
Gas Supply	Built-in air compressor
Operating Temperature	-10°C to +40°C (+14°F to +104°F)
