38 Powermax30 AIR Service Manual 808850
3 – Torch Setup
English
Material thickness
(gauge/inches)
Material Arc current (A)
Maximum cut speed
(inches/minute)
18 gauge
Mild steel 30
395
14 gauge 214
12 gauge 130
10 gauge 64
1/4 30
5/16* 22
3/8* 13
1/2* 9
5/8* 5
18 gauge
Stainless steel 30
370
14 gauge 135
10 gauge 56
1/4 24
3/8* 10
1/2* 7
1/32
Aluminum 30
400
†
1/16 306
1/8 111
1/4 38
3/8* 13
1/2* 6
* To cut material thicker than 6 mm (1/4 inch) at 240 V, start the torch at the edge of the workpiece.
† Maximum cut speed is limited by the test table’s maximum speed (10,160 mm/minute or 400 inches/minute).

Hypertherm Powermax30 AIR Specifications

General

Built-in Air Compressor	Yes
Output Voltage	83 VDC
Input Voltage	120-240 V
Current Output	15–30 A
Cutting Thickness	Up to 10 mm (3/8 in) recommended cut
Gas Supply	Built-in air compressor
Operating Temperature	-10°C to +40°C (+14°F to +104°F)
