Hypertherm Powermax30 AIR Service Manual

214 Powermax30 AIR Service Manual 808850
8 – Parts
4 428377 Kit: Internal air compressor
5 428236 Kit: Fan assembly with plenum
6 428375 Kit: Air filter assembly (includes gas hose, drain tube, and elbow fittings)
7 228143 Kit: Power cord strain relief
8 428400 Kit: Magnetics assembly
9 228210 Kit: CSA power cord with NEMA twist lock-style 240 V/20 A plug, 1-phase, 3.0 m
(10 feet)
10 428390 Kit: CE power cord, 1-phase, 3.0 m (10 feet) (plug not included)
Item Kit number Description

Hypertherm Powermax30 AIR Specifications

General

Built-in Air Compressor	Yes
Output Voltage	83 VDC
Input Voltage	120-240 V
Current Output	15–30 A
Cutting Thickness	Up to 10 mm (3/8 in) recommended cut
Gas Supply	Built-in air compressor
Operating Temperature	-10°C to +40°C (+14°F to +104°F)
