Hypertherm Powermax30 AIR Service Manual

Powermax30 AIR Service Manual 808850 61
5 – Troubleshooting and System Tests
Figure 1
6. If you do not find any problems during the visual inspection or the initial resistance check, and the power supply is still
not operating correctly, see Troubleshooting guide on page 63.
WORK LEAD (BLK)
AC AC
R
w
TORCH
START
BLK
BLK
B
TORCH
START
J22
WORK LEAD (BLK)
J16, red
J17, white

Hypertherm Powermax30 AIR Specifications

General

Built-in Air Compressor	Yes
Output Voltage	83 VDC
Input Voltage	120-240 V
Current Output	15–30 A
Cutting Thickness	Up to 10 mm (3/8 in) recommended cut
Gas Supply	Built-in air compressor
Operating Temperature	-10°C to +40°C (+14°F to +104°F)
