2.3 Installation of slider type
2-8
2. Installation
Precautions regarding stainless steel sheet
● During installation and transport, do not grasp or press on the stainless steel sheet.
Otherwise, this may lead to stainless steel sheet damage.
● Although lateral or ceiling installation is possible, it may cause slackness or
misalignment of the stainless steel sheet.
Continued usage in this orientation may lead to damage to the stainless steel sheet.
● Adjust the stainless steel sheet if slackness or misalignment occurs.
● Keep adhesive, paint, and other viscous material off the stainless steel sheet.
Such material adhering to the stainless steel sheet can lead to defective slider
operation or sheet damage.
Avoid installation in environments of this kind, or take safety measures to prevent
adhesion.
Square nuts
The square nuts regulated in JIS B1163 can be used for the T-slots.
The square nut quantities enclosed at shipping and related information are as follows.
Type
Square
nut
quantity
enclosed
Screw
size
Required bolt
length
from base
bottom
Minimum
number of
fixing
bolts
Tightening
torque
EC-S6 6 pcs M4 5 to 6mm 4 pcs
1.76N･m
EC-S7 6 pcs M5 6.5 to 8mm 4 pcs
3.42N･m
