2.5 Installation of rod type
2-23
2. Installation
Body mounting
[When using foot brackets]
ELECYLINDERs can be mounted with foot brackets (option: model FT).
For EC-R6 (Part model number EC-FT-R6)
For EC-R7 (Part model number EC-FT-R7)
Stroke + 29
Stroke + 27
