2.5 Installation of rod type
2-24
2. Installation
The accessories for the foot bracket option are as follows.
Caution
The ELECYLINDER is grounded through the installation surface.
However, it may not be grounded if it is mounted using foot brackets.
After mounting, make sure to check whether it is grounded.
If it is not, refer to " Frame grounding (page 3-4)" and connect the ground wire
to one of the two fixing screws at the bottom of the end cover.
Failure to ground may lead to malfunctions or damage to parts.
Type
(1)
Fixing bracket
(2)
Foot
bracket
(3)
Hex socket
head bolt
(4)
Square nut
(unichrome)
EC-R6 2 pcs 2 pcs
4 pcs (M4 x 10) 4 pcs (M4)
EC-R7 2 pcs 2 pcs
4 pcs (M6 x 10) 4 pcs (M6)
