IAI X-SEL - Page 447

417
INTELLIGENT ACTUATOR
Appendix
I/O Parameters
No. Parameter name
Default value
(Reference)
Input
range
Unit Remarks
312 Port number assigned to
output function selection
313
0 0 to 6999 Specify the port number to be assigned to the function of I/O
parameter No. 59, “Output function selection 313.”
* If 0 is set, the function will be assigned to output port No. 313.
(Main application version 0.64 or later/F-ROM 32-Mbit version
only)
313 Port number assigned to
output function selection
314
0 0 to 6999 Specify the port number to be assigned to the function of I/O
parameter No. 60, “Output function selection 314.”
* If 0 is set, the function will be assigned to output port No. 314.
(Main application version 0.64 or later/F-ROM 32-Mbit version
only)
314 Port number assigned to
output function selection
315
0 0 to 6999 Specify the port number to be assigned to the function of I/O
parameter No. 61, “Output function selection 315.”
* If 0 is set, the function will be assigned to output port No. 315.
(Main application version 0.64 or later/F-ROM 32-Mbit version
only)
315 Port number assigned to
output function selection
300 (area 2)
0 0 to 6999 Specify the port number to be assigned to the function of I/O
parameter No. 331, “Output function selection 300 (area 2).”
* If 0 is set, the function will not be assigned to any port.
(Main application version 0.64 or later/F-ROM 32-Mbit version
only)
316 Port number assigned to
output function selection
301 (area 2)
0 0 to 6999 Specify the port number to be assigned to the function of I/O
parameter No. 332, “Output function selection 301 (area 2).”
* If 0 is set, the function will not be assigned to any port.
(Main application version 0.64 or later/F-ROM 32-Mbit version
only)
317 Port number assigned to
output function selection
302 (area 2)
0 0 to 6999 Specify the port number to be assigned to the function of I/O
parameter No. 333, “Output function selection 302 (area 2).”
* If 0 is set, the function will not be assigned to any port.
(Main application version 0.64 or later/F-ROM 32-Mbit version
only)
318 Port number assigned to
output function selection
303 (area 2)
0 0 to 6999 Specify the port number to be assigned to the function of I/O
parameter No. 334, “Output function selection 303 (area 2).”
* If 0 is set, the function will not be assigned to any port.
(Main application version 0.64 or later/F-ROM 32-Mbit version
only)
319 Port number assigned to
output function selection
304 (area 2)
0 0 to 6999 Specify the port number to be assigned to the function of I/O
parameter No. 335, “Output function selection 304 (area 2).”
* If 0 is set, the function will not be assigned to any port.
(Main application version 0.64 or later/F-ROM 32-Mbit version
only)
320 Port number assigned to
output function selection
305 (area 2)
0 0 to 6999 Specify the port number to be assigned to the function of I/O
parameter No. 336, “Output function selection 305 (area 2).”
* If 0 is set, the function will not be assigned to any port.
(Main application version 0.64 or later/F-ROM 32-Mbit version
only)
321 Port number assigned to
output function selection
306 (area 2)
0 0 to 6999 Specify the port number to be assigned to the function of I/O
parameter No. 337, “Output function selection 306 (area 2).”
* If 0 is set, the function will not be assigned to any port.
(Main application version 0.64 or later/F-ROM 32-Mbit version
only)
322 Port number assigned to
output function selection
307 (area 2)
0 0 to 6999 Specify the port number to be assigned to the function of I/O
parameter No. 338, “Output function selection 307 (area 2).”
* If 0 is set, the function will not be assigned to any port.
(Main application version 0.64 or later/F-ROM 32-Mbit version
only)
323 Port number assigned to
output function selection
308 (area 2)
0 0 to 6999 Specify the port number to be assigned to the function of I/O
parameter No. 339, “Output function selection 308 (area 2).”
* If 0 is set, the function will not be assigned to any port.
(Main application version 0.64 or later/F-ROM 32-Mbit version
only)
324 Port number assigned to
output function selection
309 (area 2)
0 0 to 6999 Specify the port number to be assigned to the function of I/O
parameter No. 340, “Output function selection 309 (area 2).”
* If 0 is set, the function will not be assigned to any port.
(Main application version 0.64 or later/F-ROM 32-Mbit version
only)
