370 Implementing the IBM Storwize V5000 Gen2 with IBM Spectrum Virtualize V8.1

3. Select from the host list the hosts to which the imported volumes will be mapped, as

shown in Figure 7-22, and click Next.

Figure 7-22 Modify host mappings

Note: If you select Host Clusters in the Create Mapping panel, you need to ensure that

the host cluster has consistent access to I/O groups. If each host in the host cluster

does not have access to the same I/O groups, mappings to volumes will fail.
