72 Implementing the IBM Storwize V5000 Gen2 with IBM Spectrum Virtualize V8.1
2. If the enclosure is cabled correctly, the wizard identifies the candidate expansion
enclosure. Select the expansion enclosure and click Next, as shown in Figure 2-45.
Figure 2-45 Expansion enclosure cable check
3. Select the expansion enclosure and click Actions → Identify to turn on the identify LEDs
of the new enclosure, if required. Otherwise, click Next.

IBM Storwize V5030 Specifications

General

Model	IBM Storwize V5030
Category	Storage
Controller Enclosures	1 or 2
Maximum Drives	240
RAID Levels	0, 1, 5, 6, 10
Virtualization	Yes
Data Compression	Yes
Maximum Hosts	512
Form Factor	2U
Drive Types	SAS, NL-SAS, SSD
Host Interface	8 Gb FC, 16 Gb FC, 10 Gb iSCSI, 12 Gb SAS
Processor Cores	8 per controller
