Table 3. 3958 AP1 server rear view: Slot assignments, ports, and connections for
VTL (continued)
P2 Power connection
Server rear view, OpenStorage
When configured for OpenStorage, the 3958 AP1 servers are equipped with
v one of the following two Ethernet adapter configurations:
– If two instances of Feature Code 3456 are installed, three 1-Gb quad-port
Ethernet adapters
– If two instances of Feature Code 3457 are installed, two 10-Gb dual-port
Ethernet adapters for use with Fibre Channel cabling and one 1-Gb quad-port
Ethernet adapter
v two dual-port Qlogic Fibre Channel HBAs
v two on-board Ethernet ports
See Figure 6, Figure 7, and Table 4.
Table 4. 3958 AP1 server rear view: Slot assignments, ports, and connections for
OpenStorage
Connection OpenStorage use, FC 3456 OpenStorage use, FC 3457
1 Slot 1 Blank
2 Slot 2 Blank
ts760753
ProtecTIER Server
11 1
1
22 22
1
2
3
4
5
6
7
E1
E2
1
3
4
3
3
2
4
4
P1
P2
8
A1
A2
9
B
V
E3
E4
S
Figure 6. 3958 AP1 server rear view with OpenStorage configuration, Feature Code 3456
Figure 7. 3958 AP1 server rear view with OpenStorage configuration, Feature Code 3457
