Table 20. Clustered power connections
Label From To Remarks
1 Bottom PDU J10 Lower Ethernet switch
2 Top PDU J10 Upper Ethernet switch
3 Bottom PDU J4 System console (TSSC)
Ethernet switch
4 Top PDU J4 TSSC KVM assembly
5 Bottom PDU J5 System console, plug 1
6 Top PDU J5 System console, plug 2 Use dependent on
customer order
7 Bottom PDU J3 KVM Switch
8 Top PDU J8 DD4A P1 Not used currently
9 Bottom PDU J8 DD4A P1 Not used currently
10 Top PDU J8 pigtail DD4A P1 Stand-alone installation
only
11 Top PDU J8 Top PDU J8 pigtail Stand-alone installation
only
12 Bottom PDU J8 pigtail DD4A P2 Stand-alone installation
only
13 Bottom PDU J8 Bottom PDU J8 pigtail Stand-alone installation
only
14 Top PDU J8 Network power switch
main bus power (bus A)
15 Bottom PDU J8 Network power switch
backup bus power (bus
B)
16 DD4A P1 Network power switch,
plug A1
17 DD4A P2 Network power switch,
plug B1
18 DD4B P1 Network power switch,
plug A2
19 DD4B P2 Network power switch,
plug B2
20 CNA-1 P2
EXPA1-1 P2
Bottom PDU J1 Bifurcated cable
21 CNB-1 P1
EXPB1-1 P1
Top PDU J1 Bifurcated cable
22 EXPA1-2 P1
EXPA1-3 P1
Bottom PDU J2 Bifurcated cable
23 EXPB1-2 P1
EXPB1-3 P1
Top PDU J2 Bifurcated cable
24 CNA-2 P2
EXPA2-1 P2
Bottom PDU J6 Bifurcated cable
25 CNB-2 P1
EXPB2-1 P1
Top PDU J6 Bifurcated cable
26 EXPA2-2 P2
EXPA2-3 P2
Bottom PDU J7 Bifurcated cable
Chapter 3. Installing the appliance 49
