D Scope set mode (continued)
5
FUNCTIONS FOR RECEIVE
Scope during Tx (CENTER Type) ON
Turn display of the transmit signal ON or OFF. NOTE: Transmit signal display is available for the
center mode only.
Max Hold ON
Turn the peak level hold function ON or OFF.
CENTER Type Display Filter Center
Select the center frequency of the spectrum scope
display (center mode only).
•FilterCenter :Showstheselectedfilter’scenter
frequency at the center.
•CarrierPointCenter
: Shows the selected operating
mode carrier point frequency at the
center.
•CarrierPointCenter(Abs.Freq.)
: In addition to the carrier point
center setting above, the actual fre-
quency is displayed at the bottom
of the scope.
Waveform Type Fill
Select the outline indication of the waveform for the
spectrum scope.
•Fill : The waveform is described by only
the color.
•Fill+Line :Thewaveformisdescribedbythe
color and outline.
Waveform Color (Current) 217 241 247
Set the waveform color for the currently received sig-
nals.
•ThecolorissetinRGBformat.
•Push[t u]
F-3
to select R (Red), G (Green) and
B (Blue), and rotate the ratio from 0 to 255 range.
•Thesetcolorisindicatedintheboxbesidethe
RGB scale.
Waveform Color (Line) 70 30 0
Set the waveform color for the currently received sig-
nals.
•ThecolorissetinRGBformat.
•Push[F-3•Ω ≈] to select R (Red), G (Green) and B
(Blue), and rotate the ratio from 0 to 255 range.
•ThesetcolorisindicatedintheboxbesidetheRGB
scale.
Waveform Color (Max Hold) 58 110 147
Setthewaveformcolorforthereceivedsignalsmax-
imum level.
•ThecolorissetinRGBformat.
•Push[t u]
F-3
to select R (Red), G (Green) and
B (Blue), and rotate the ratio from 0 to 255 range.
•Thesetcolorisindicatedintheboxbesidethe
RGB scale.
