MEMORY/CALL CHANNELS
N Programming memory/bank/scan name
Each memory channel can be programmed with an alpha-
numeric channel name for easy recognition and can be in-
dicated independently by channel. Memory and scan names
can be a maximum of 8 characters, and bank name can be a
maximum of 6 characters.
NOTE: Scan name indication can be turned ON or OFF in
DISP set mode (SET). (p. 131)
q Push [M/CALL] to select the memory mode.
• To program a call channel name, push [M/CALL] to select the
call channel mode.
w Rotate [DIAL] to select the desired memory channel.
• Select scan edge channels (0A/0B to 24A/24B) to program a scan
name.
e Push [S.MW] to enter the select memory write mode.
• “X” indicator and the memory channel number blink.
r
Push
[ ](MONI)
.
t Rotate [DIAL] to select “B NAME,” “M NAME” or “S NAME”
when programming the bank name, the memory name or
the scan name, respectively.
y
Push [ ](MONI).
• A cursor blinks for the first character.
u Rotate [DIAL] to select the desired character.
• The selected character blinks.
• Push [
](LOW) to move the cursor right; push [
](CS) to move
the cursor left.
•
Push [CLR](DR) to erase the selected character, or push and hold
[CLR](DR) for 1 sec. to erase all characters following the cursor.
i Repeat step u until the desired channel name is pro-
grammed.
o
Push [ ](MONI).
!0 Push and hold [MW](S.MW) for 1 sec. to set the name and
exit channel name programming state.
• 3 beeps sound.
NOTE: Only one bank name can be programmed into
each bank. Therefore, the previously programmed bank
name will be displayed when bank name indication is se-
lected. Also, the programmed bank name is assigned for
the other bank channels automatically.
D Available characters
(A) (B) (C) (D) (E) (F) (G) (H) (
I
) (J) (K) (L) (M)
(N) (O) (P) (Q) (R) (S) (T) (U) (V) (W)
(9) (!) (”)(0) (1) (2) (3) (4) (5) (6) (7) (8)
(:)
($) (%) (&) (
’
)
(
;
)(
<
)(
=
) (>) (?)
(
(
)
(X) (Y) (Z)
(#)
(
+
)
(
/
)
(
)
)(
)(
,
)(
-
)(
.
)
(
\
)
(
@
)(
)
(
]
)(
^
)(
Space
)
