Icom ID-E880

145
11
DTMF MEMORY ENCODER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
N DTMF speed
The rate at which DTMF values in memory send individual
DTMF characters can be set to accommodate operating
needs.
q Enter “DTMF-S” in DUP.T menu.
MENU ¶ DUP.T ¶ DTMF-S
(p. 122)
(Push [MENU ]), (rotate [DIAL], then push [ ](MONI).)
[DIAL]
[MENU ]
[ ]
w Rotate [DIAL] to select and set the desired speed as
shown in the table below, then push [
](MONI).
e Push [MENU
] again to exit DUP.T menu and return to
the frequency screen.
DISPLAY INTERVAL SPEED
100 100 msec. 5.0 cps
200 200 msec 2.5 cps
300 300 msec. 1.6 cps
500 500 msec. 1.0 cps
cps=characters/sec
N Clearing a DTMF memory
An unwanted DTMF memory can be cleared (erased).
q Push and hold [DTMF](MONI) for 1 sec. to enter the DTMF
set screen.
w Rotate [DIAL] to select
“DTMF-M,” then push [ ](MONI).
e Rotate [DIAL] to select the desired DTMF memory chan-
nel to be cleared, then push [
](MONI).
r Rotate [DIAL] to select “--,” then push [
](MONI) to clear
the selected DTMF memory channel.
[DIAL]
[MENU ]
[ ]
After clearing the DTMF memory.
Rotate [DIAL]
When entering DTMF programming mode.
t Push [MENU ] to exit the DTMF set screen.
