70
5
DV MODE OPERATION
N
Low-speed data communication
In addition to the digital voice communication, low-speed data
communication is available.
Use the optional OPC-1529R
DATA COMMUNICATION CABLE with
third-party serial data communication software.
NOTE: Turn OFF "GPS-TX" (p. 138) in advance to operate
the low-speed data communication.
D Connection
Connect the transceiver to your PC using with the optional
OPC-1529R as illustrated below.
OPC-1529R
(optional)
to [DATA]
to RS-232C
port
D Low-speed data communication application
setting
Configure the serial data communication software as follows.
• Port : The COM port into which you plugged the
OPC-1529R
• Baud rate : 9600/4800
bps (p. 129)
• Data : 8 bit
• Parity : None
• Stop : 1 bit
• Flow control : Xon/Xoff
D Low-speed data communication operation
NOTE: Confirm that when in AUTO, the computer controls
[PTT] to send data. In AUTO you should not have to push
[PTT] to send data.
q Set the current call signs, etc. as described in “Current call
sign setting” (p. 42), “Simplex operation in the VFO” (p. 56)
and “D-STAR repeater operation in the VFO” (p. 58).
w Follow the instructions for the data communication soft-
ware.
e To transmit data
• At the same time as your voice audio, push and hold [PTT] to
transmit while sending data from the PC. Release [PTT] to re-
ceive.
• Under computer control, see Transmission condition setting at
right.
To Next Page
