Icom ID-E880

5
1
PANEL DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
i MEMORY CHANNEL NUMBER INDICATORS
± Shows the selected memory channel number. (pgs. 12, 88)
± Shows the selected bank initial. (p. 93)
± “C0” or “C1” appears when the call channel is selected.
(pgs. 13, 89)
o DR (D-STAR REPEATER) INDICATOR (pgs. 13, 50, 52)
Appears when the DR mode is selected.
!0 AUTO POWER OFF INDICATOR
(p. 129)
Appears when the auto power OFF function is in use.
!1 GPS INDICATOR
Appears when a GPS receiver is connected and a valid posi-
tion data is received; blinks when an invalid data is received.
• GPS indicator can be turned OFF in GPS.SET mode. (p. 138).
!2 MEMORY INDICATOR (pgs. 12, 88)
Appears when the memory mode is selected.
!3 PRIORITY INDICATOR
(pgs. 112, 113, 115)
Appears while priority watch is activated, blinks while pri-
ority watch is paused.
!4 SKIP INDICATOR
(p. 108)
± “ ” appears when the displayed memory channel is
specified as a skip channel.
± “
” appears when the displayed frequency is speci-
fied as a program skip frequency.
!5 TONE INDICATOR
• During FM/FM-N mode operation:
± “T” appears while the repeater tone is in use. (p. 23)
± “T SQL” appears while the tone squelch function is in
use.
(p. 146)
± “T SQL-R” appears while the reverse tone squelch
function is in use.
(p. 147)
± “DTCS” appears while the DTCS squelch function is
in use.
(p. 146)
± “DTCS -R” appears while the reverse DTCS squelch
function is in use.
(p. 147)
± “ ” appears with the “T SQL” or “DTCS” indicator
while the pocket beep function is in use.
(p. 146)
• During DV mode operation:
± “D SQL” appears while the digital call sign squelch
function is in use.
(p. 151)
± “CSQL” appears while the digital code squelch
function is in use.
(p. 151)
± “ ” appears with the “D SQL” or “C SQL” indicator
while the pocket beep function is in use.
(p. 151)
!6 DUPLEX INDICATORS (p. 23)
“DUP” appears when plus duplex, “DUP–” appears when
minus duplex (repeater) operation is selected.
!7 KEY LOCK INDICATOR
(p. 16)
Appears when the key lock function is activated.
